SUA5000RMT5U
$3,275.00 Configured Summary
SUA5000RMT5U
APC 5000VA 4000W 208V Rackmount/Tower Smart-UPS

APC Smart-UPS,4000 Watts /5000 VA,Input 208V /Output 208V, Interface Port DB-9 RS-232, SmartSlot, Rack Height 5U
Note: Image above may show a varied configuration or optional part. Please refer to parts list for standard parts included.
SKU SUA5000RMT5U
Details
Output
Output Power Capacity:
4000 Watts / 5000 VA
Max Configurable Power:
4000 Watts / 5000 VA
Nominal Output Voltage:
208V
Output Voltage Distortion:
Less than 5% at full load
Output Frequency (sync to mains):
47 - 53 Hz for 50 Hz nominal, 57 - 63 Hz for 60 Hz nominal
Topology:
Line Interactive
Waveform Type:
Sine wave
Output Connections
2x NEMA L6-20R
2x NEMA L6-30R

Input
Nominal Input Voltage:
208V
Input Frequency:
50/60 Hz +/- 5 Hz (manual switch)
Input Connections:
NEMA L6-30P
Cord Length:
2.44 meters
Input voltage range for main operations:
141 - 255V
Input voltage adjustable range for mains operation:
131 - 268V

Communications & Management
Interface Port(s):
DB-9 RS-232, SmartSlot
Pre-Installed SmartSlot™ Cards:
AP9630
Control panel:
LED status display with load and battery bar-graphs and On Line : On Battery : Replace Battery : and Overload Indicators
Audible Alarm:
Alarm when on battery : distinctive low battery alarm : configurable delays
Emergency Power Off (EPO):
Optional

Surge Protection and Filtering
Surge energy rating:
480 Joules
Filtering:
Full time multi-pole noise filtering : 0.3% IEEE surge let-through : zero clamping response time : meets UL 1449

Physical
Maximum Height:
222.00 mm
Maximum Width:
483.00 mm
Maximum Depth:
660.00 mm
Rack Height:
5U

Environmental
Operating Environment:
0 - 45 °C
Operating Relative Humidity:
0 - 95%
Operating Elevation:
0-3000 meters
Storage Temperature:
-5 - 55 °C
Storage Relative Humidity:
0 - 95%
Storage Elevation:
0-15000 meters
Audible noise at 1 meter from surface of unit:
53.00 dBA
Online Thermal Dissipation:
344.00 BTU/hr

Conformance
Regulatory Approvals:
CSA, FCC Part 15 Class A, UL 1778
Standard Warranty:
2 years repair or replace

Sustainable Offer Status
RoHS:
Compliant
Other Environmental Compliance:
China RoHS
SUA5000RMT5USUA5000RMT5U
Note: Image above may show a varied configuration or optional part. Please refer to parts list for standard parts included.
